Product Description
The PGB.0631.100 Manometer from Parker features a 63mm diameter and R1/4 below connection, with a pressure range of 0-100 bar. This reliable pressure gauge is available in various ranges up to 600 bar and with multiple connection options.
Additional information
Product Specifications
| Part Number | PGB0631100 | Brand | Parker |
| Product Type | Pressure Gauge | Materials of Construction | Case: BS 304 S15 Stainless Steel Window: Acrylic Movement: Brass Dial: White Aluminium Pointer: Black Aluminium |
| Diameter | 63 mm (2.5 inch) | Division | Hydraulic & Industrial Process Filtration Division EMEA | Hydraulic and Industrial Process Filtration EMEA |
| Options | Bourdon Tube: Phosphor bronze, C-type | Operating Pressure | 0-100 bar (0-1450 psi) |
| Ingress Protection Rating | IP 65 | Port Size | G1/4 |
| Connection Type | Bottom |
