PGB.0631.025 Manometer Ø63 R1/4 below, 0-25 bar
$69.69
- Payment by invoice possible
- Not currently in stock, contact us for factory lead times
- Payment by invoice possible
- In stock at factory, ready to ship in estimated 1-2 weeks, contact us for expedited options
- Del Rey is proud to be the exclusive distributor of Waagene products
- Payment by invoice possible
- Low quantities typically kept on hand; please contact us for availability at lead time
- Authorized MiniBOOSTER distributor & hydraulic excellence partner
Product Description
Parker’s PGB.0631.025 Manometer is designed for reliable visual indication of system pressure. This pressure gauge features a Ø63 diameter and R1/4 connection. It is available in a 0-25 bar range, with options for higher pressure up to 600 bar and various connection choices.
Additional information
Product Specifications
| Part Number | PGB0631025 | Brand | Parker |
| Product Type | Pressure Gauge | Materials of Construction | Case: BS 304 S15 Stainless Steel Window: Acrylic Movement: Brass Dial: White Aluminium Pointer: Black Aluminium |
| Diameter | 63 mm (2.5 inch) | Division | Hydraulic & Industrial Process Filtration Division EMEA | Hydraulic and Industrial Process Filtration EMEA |
| Options | Bourdon Tube: Phosphor bronze, C-type | Operating Pressure | 0-25 bar (0-232 psi) |
| Ingress Protection Rating | IP 65 | Port Size | G1/4 |
| Connection Type | Bottom |
