Product Description
The OMC-140 is the new self designed and developed multifunctional TFT Display of Observator. Wherever you need to visualize your critical measurement information on a dedicated instrument the OMC-140 can be applied. Whether it is presenting wind information or indication of other meteorological parameters, the OMC-140 is the ideal instrument. Due to its modular design, the OMC-140 may also act as an intelligent signal converter. Further the unit is provided with a memory card slot, in case the OMC-140 should act as a basic data logger as well. The unit is also provided with a LAN interface in order to have your information available within your network and is provided with bus-connectors to create a multiple indication and I/O network.
Additional information
Product Specifications
| Inputs/Outputs | 2 NMEA0183 inputs 1 NMEA0183 output Micro USB (programming purposes) RJ45 LAN connector Display interconnection bus More I/O possible through the option boards |
| TFT Touch Screen | 8,5” Super Wide Viewing Angle 170° LCD with long life and low power LED backlight |
| Active Display Area | 184.8 x 110.9 mm |
| Screen Resolution | WVGA 800×480 |
| Electrical | 100..240 Vac, 50/60 Hz, max 50 VA Sensor 1 and 2 power output 15..16.5 Vdc max 1.5 W Connections, pluggable screw terminals for max 2.5 mm² |
| Dimensions | Packing 30 x 30 x 40 cm Weight 1.2 kgs |
| Alarms | Build-in alarms on parameters and system functioning Outputs, potential free relay outputs through OMC-140-2 |
Features
- 8.5” Super Wide Viewing Angle 170° LCD with long life and low power LED backlight.
- Touch screen display.
- Power supply between 90 and 250 Vac.
- 2 RS422 NMEA inputs, status LED available.
- 2 pcs power supply for connected sensors, status LED available.
- 1 pce NMEA output, status LED available.
- Alarm handling, high and high-high, audible and visible, acceptance possible.
- Three option slots available for additional I/O and functionality.
- Memory card facility.
- RJ45 LAN connection.
- Interconnection bus for more displays.
- Suitable for 144 x 144 instrument replacement (portrait or landscape).
- DNV type approval pending.
