Manometer 63mm, 0-40 bar
$75.80
- Payment by invoice possible
- Not currently in stock, contact us for factory lead times
- Payment by invoice possible
- In stock at factory, ready to ship in estimated 1-2 weeks, contact us for expedited options
- Del Rey is proud to be the exclusive distributor of Waagene products
- Payment by invoice possible
- Low quantities typically kept on hand; please contact us for availability at lead time
- Authorized MiniBOOSTER distributor & hydraulic excellence partner
Product Description
Parker’s 63mm Manometer features a 0-40 bar range and offers clear visual pressure indication. With pressure options up to 600 bar and a variety of connection choices, it ensures reliable system monitoring.
Additional information
Product Specifications
| Part Number | PGF0631040 | Brand | Parker |
| Product Type | Pressure Gauge | Materials of Construction | Case: BS 304 S15 Stainless Steel Window: Acrylic Movement: Brass Dial: White Aluminium Pointer: Black Aluminium |
| Diameter | 63 mm (2.5 inch) | Division | Hydraulic & Industrial Process Filtration Division EMEA | Hydraulic and Industrial Process Filtration EMEA |
| Options | Bourdon Tube: Phosphor bronze, C-type | Operating Pressure | 0-40 bar (0-580 psi) |
| Ingress Protection Rating | IP 65 | Port Size | G1/4 |
| Connection Type | Panel Mounting / 3-Hole Flange |
