Product Description
The product is a 17.0 inch Maritime Multi Display (MMD) from Hatteland Display AS, model JH 17T02 MMD, designed for professional maritime applications. The display is adaptable for various environments with adjustable brightness and offers a comprehensive range of technical specifications including a 1280×1024 resolution, a 1500:1 contrast ratio, and multiple signal input compatibility.
Additional information
PRODUCT SPECIFICATIONS
Technical Sprcifications
TFT Technology:
- 17.0 inch viewable image size
- a-Si TFT (Thin Film Transistor) Active Matrix
- PVA (Plus Viewing Angle)
TFT Characteristics:
| Pixel Number | 1280 x 1024 |
|---|---|
| Pixel Pitch (RGB) | 0.264 (H) x 0.264 (V) mm |
| Response Time | 10 ms (typical), “black” to “white” |
| Contrast Ratio | 1500:1 (typical) |
| Light Intensity | 280 cd/m2 (typical) |
| Viewable Angle | +/- 89 deg. (typical) (Up/Down/Left/Right) |
| Active Display Area | 337.92 (H) x 270.336 (V) mm |
| Max Colors | 16.7 millions (depending on graphics card) |
Synchronisation:
Sync Signal:
- Digital separate synchronisation.
- Composite synchronisation.
- Synchronisation on green..
- Auto detects VGA -> SXGA, interlaced and non interlaced.
Video Signal:
- Analog RGB 0,7Vp-p
- Input Impedance 75 Ohm.
Synchronisation Range:
- Horizontal : 15,0 kHz to 91,1 kHz.
- Vertical : 60 Hz* to 85 Hz.
Supported Signals:
Resolutions:
| VGA | 640 x 480 (including 640 x 350) |
| SVGA | 800 x 600 (including 720 x 400) |
| XGA | 1024 x 768 |
| SVGA | 1280 x 1024 |
| XGA | 1600 x 1200 |
| SXGA | 1920 x 1200 |
Interlaced NTSC and PAL/SECAM video
- Composite video
- S-Video
Power Specifications:
Power Supply:
| 115& 230VAC – 50 / 60Hz | – JH 19T12 MMD-Axx-xxxx |
| 24 VDC | – JH 19T12 MMD-Dxx-xxxx |
Power Consumption:
| Operating | 38 W (typ) – Measured at 230Vrms |
| Operating | 37,2 W (typ) – Measured at 24VDC |
| Operating | 60W (max) |
Mechnical Sprcifications
Physical Dimensions:
- Width: 460 mm (18.11″)
- Height: 462.4 mm (18.20″)
- Depth: 217.8 mm (8.57″)
Input Signal Terminal:
| Signal Type | Connector Type |
|---|---|
| DVI-I (PC) signal | DVI-I Input 29pin Connector |
| RGB (PC) signal | 15pin mini D-SUB (female – Input) |
| Composite Video | RCA Phono plug |
| S-Video signal | S-Video (SVHS) plug |
| AC Power signal | Std IEC Inlet Model JH 17T02 MMD A1 |
| DC Power signal | Screw terminal Model JH 17T02 MMD A2 |
Accessories:
| Touchscreen | 1 x D-SUB 9P Connector (female) |
|---|---|
| Remote Control | 2 x D-SUB 9P Connector (female) |
User Controls:
On Front Bezel:
- Power On/Off (push button)
- Brightness Control
- 2 x hotkeys
- Mode Status LED
Behind Hatch:
- On Screen Display control (OSD/OSM)
Environmental Consideration:
| Operating | Temperature -15 deg. C to +55 deg. C Humidity up to 95% |
| Storage | emperature -20 deg. C to +60 deg. C Humidity up to 95% |
| IP Rating | EN60529 (IP66) (Applies for flush mounting) |
Safety Consideration:
Even although the test conditions for bridge units provide for a maximum operating temperature of 55°C, continuous operation of all electronic components should, if possible, take place at ambient temperatures of only 25°C. This is a necessary prerequisite for long life and low service costs. Available option: JH MMD BRBracket for JH MMDRO (Rotary Bracket)*Option: Standard or custom logo and color The JHVBUF is tested at resolutions up to 1600 x 1200. Both separate sync and composite sync is supported. The VGA output signal is at same resolution and sync as the input. The output is working even if the main display is turned off. (Power supply must be connected though).
Available Options:
| JH MMDRO | Rotary Bracket |
| JH 17TSV | Sun Visor |
| JH VESA 17T01 | VESA Bracket |
| JH 17TAP STD-A1 | 17″ TFT to 19″ Rack Adapter Frame/Plate |
| JH VBUF | Video Buffer (1) |
| JH SCOM | Remote Control |
| JH XPR | External Power Relay |
| Touch Screen | Factory mounted |
