F4-E20 Luminescent flat Stair Nosing IL-F4
- Payment by invoice possible
- In stock at factory, ready to ship in estimated 1-2 weeks, contact us for expedited options
- Del Rey is proud to be the exclusive distributor of iLumiGlo products
- Del Rey is proud to be the exclusive distributor of Waagene products
- Payment by invoice possible
- Low quantities typically kept on hand; please contact us for availability at lead time
- Authorized MiniBOOSTER distributor & hydraulic excellence partner
Product Description
Ecoglo®’s expertly engineered F4-E20 Photoluminescent Anodized Flat Stair Nosing is designed to enhance egress speeds in all lighting conditions and provide exceptional step-edge visibility. After gaining a full charge from exposure to either a natural or artificial light source, the integrally bonded photoluminescent brightly lights stairways after the power has gone out to safely guide occupants to the exit discharge. This versatile non-slip aluminum stair nosings can be installed on a variety of substrates such as concrete, timber, tiles, checker plate, steel and thin carpet. Our patented manufacturing process brings you the very best in luminescent properties, ensuring you have a luminous egress product you can trust. The safety of all people in a facility depends on a clear egress plan and advance site preparation including clear marking of escape routes. Photoluminescent egress marking systems installed in exit stairwells are a critical, code-required component of any building safety system. Photoluminescent markings are always on, full proof systems to guide people out of buildings during any type of emergency conditions. Charges with ambient light. Always-on visible light. No electricity required. Our photoluminescent systems are comprised of materials including aluminum, epoxies, PVC, tapes, and paints . A one-inch wide “glowing” stripe is applied to the leading edge the steps, on handrails, and along the perimeter of landings and pathways leading out of the building. General Information Install our stair strips using polyurethane adhesive and mechanical fasteners. The product can also be installed using only the adhesive. This metal stair nosing comes supplied with pre-drilled countersunk holes, including stainless steel fasteners and concrete nylon anchors. The standard hole is located 2” from each end and approximately 12” apart. The standard lengths for our metal stair nosing are 8ft and 10ft, but this illuminated stair nosing is also available in cut to length sizes (Tolerance + or – 1/8”). Inserts can come Attached or Unattached – Unattached is recommended for on-site cutting. Use premium polyurethane adhesive to install Ecoglo® inserts. This egress signage weighs 0.44 lbs/ft. Aluminum Finish: This abrasive stair nosing is available in 6063 – T5 Aluminum, Mill Finish, or with Clear or Black Anodized Finish (Anodized to Type 2, Class 1. 20 microns thickness). Light Bronze and Dark Bronze Anodized finishes are available at an additional cost.
Additional information
Product specification
- Install our stair strips using polyurethane adhesive and mechanical fasteners. The product can also be installed using only the adhesive.
- This metal stair nosing comes supplied with pre-drilled countersunk holes, including stainless steel fasteners and concrete nylon anchors. The standard hole is located 2” from each end and approximately 12” apart.
- The standard lengths for our metal stair nosing are 8ft and 10ft, but this illuminated stair nosing is also available in cut to length sizes (Tolerance + or – 1/8”).
- Inserts can come Attached or Unattached – Unattached is recommended for on-site cutting. Use premium polyurethane adhesive to install Ecoglo® inserts.
- This egress signage weighs 0.44 lbs/ft.
Aluminum Finish:
- This abrasive stair nosing is available in 6063 – T5 Aluminum, Mill Finish, or with Clear or Black Anodized Finish (Anodized to Type 2, Class 1. 20 microns thickness).
- Light Bronze and Dark Bronze Anodized finishes are available at an additional cost.
Metal Stair Nosing Engineered for Durability:
- We manufacture our aluminum stair nosing using Ecoglo®’s patented process to produce the most durable and efficient photoluminescent product available.
- The unique ridges in the photoluminescent strips protect the product from most abrasive wear – providing slip resistance while allowing the aluminum stair nosing to be easily cleaned.
- Our stair strips can withstand the rigors of thousands of people walking on them and show no signs of wear and tear thanks to the hard-wearing silicon carbide non-slip material we integrally bonded to the aluminum substrate.
- The thick anodized finish of our aluminum stair nosing is aesthetically pleasing, prevents corrosion, is abrasion resistant, and extremely hard. Its anodized aluminum surface is harder than pure aluminum, which is second only to diamond’s strong crystalline structure.
Step Edge Safety:
- The color of the advanced photoluminescent technology provides a stark contrast to the non slip steps, providing step edge visibility in all light conditions.
- Our team designed unique ridges into the Ecoglo® photoluminescent strips and the integrated anti slip contrast slips to provide unique all-weather slip resistance – providing sure footing even in the pouring rain.
Stair Covers For Indoor Use and Outdoor Use:
- We used accelerated UV/weathering exposure to test our stair strips’ quality and have proven it is highly resistant to such UV/weathering effects.
- When subjected to 6,000 hours of UV exposure – which is similar to 30 years of outdoor exposure – the loss in the product’s performance is less than can be detected by the human eye.
- Ecoglo® uses a “long chain” polymer in our patented manufacturing process to form strong UV resistant aluminum stair nosings when bonding.
Environmentally Friendly Luminescent Aluminum Flat Stair Nosing:
- This aluminum stair nosing product is LEED points qualified thanks to its great energy efficiency and “green” virtues.
- These stair strips will consume zero energy throughout their lifespan, as they will be solely powered by existing lights in your facility.
- This product is non-radioactive and non-toxic – a core trait of every Ecoglo® product.
- We designed our aluminum nosing to be completely recyclable and will cost you nothing to dispose of.
